Technical Overview
Sound power at max. speed (2010/30/EC)
55 dB
Maximum output air extraction
468 m³/h
Boost position air extraction
828 m³/h
Color body
Black
Material body
Glass, Lacquered
Built-in / Free-standing
Built-in
Type of appliance width
90 cm
Specifications
Type of appliance width
90 cm
Color body
Black
Installation typology
Wall-mounted
Operating Mode
Convertible
Total power of the motors
160 W
Type of control setting and signalling devices
touch control
Number of speed settings
อัตราความเร็ว
Maximum output air extraction
468 m³/h
Boost position air extraction
828 m³/h
Sound power at max. speed (2010/30/EC)
55 dB
Sound power boost (2010/30/EC)
69 dB
Maximum output recirculating air
378 m³/h
Boost position output recirculating
460 m³/h
ระดับเสียง
67 dB
ระดับเสียง
71 dB
Grease filter material
Washable aluminium
Total annual energy consumption
28.5 kWh/annum
Height of the appliance
323 mm
Width of the appliance
890 mm
Depth of the product
499 mm
Minimum distance above an electric hob
450 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
Yes
Length electrical supply cord
130 cm
Net weight
23.1 kg
PerfectAir
No
SilentPowerDrive
Yes
Super Silent
Yes
Clean filter reminders
No
Boost position
Yes
Delay Shut off modes
No
Remote control
No
Type of lamps used
LED
Color temperature
Neutral (3.500 K)
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Hob-based hood control
No
